Cisco CTS-EX60-K9= Accessory

Part Number: CTS-EX60-K9=
Model: Parts

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
ITU-T Recommendation
H.323
Video Bridging
Point-to-Point
Image Sensor Size
1/3
Image Sensor Type
CMOS

Product Description:

  Cisco TelePresence EX 60 Web Conference Equipment - CMOS - 1920 x 1200 Video - H.323 - Point-to-Point - 60 fps - 2 x Network (RJ-45)Audio Line In - USB - Gigabit Ethernet - Internal Microphone(s) - Wall Mountable

Cisco Parts Accessory Model Overview

Products and parts from Cisco.
Cisco CTS-EX60-K9= Accessory Overview

The Cisco TelePresence System EX Series transforms the workplace by combining work, communications, and collaboration - all on the desktop with just the touch of a finger. Colleagues can instantly work together whether they are separated by a hallway, a street, or several time zones. As part of the EX Series, the Cisco TelePresence System EX90 (EX90) and Cisco TelePresence System EX60 (EX60) support vivid, lifelike 1080p30 video, natural collaboration, and the simplicity of a touch screen interface for a complete solution that helps ensure conversations are more productive.

Technical Information
ITU-T Recommendation:
H.323
Video Bridging:
Point-to-Point
Camera
Image Sensor Size:
1/3
Image Sensor Type:
CMOS
Video
Graphics Modes:
WUXGA
Maximum Video Resolution:
1920 x 1200
Maximum Frame Rate:
60 fps
Video Encoding:
  • H.261
  • H.263
  • H.263+
  • H.264
  • H.239
Audio
Microphone Form Factor:
Internal
Audio Encoding:
  • G.722
  • G.722.1
  • G.711
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Interfaces/Ports
Audio Line In:
Yes
Network (RJ-45):
Yes
USB:
Yes
Number of Network (RJ-45) Ports:
2
Number of Audio Line In:
1
Physical Characteristics
Form Factor:
Wall Mountable
Height:
20"
Width:
20.5"
Depth:
5.4"
Weight (Approximate):
12.90 lb
Miscellaneous
Package Contents:
  • TelePresence EX 60 Web Conference Equipment
  • Codec
  • Display
  • Camera
  • Microphone and loudspeakers
  • Cables including: DVI-I-to-VGA cable, DVI-D cable, 3.5-mm jack audio cable, LAN cable, power adapter, and power cable
Additional Information:
  • A high-quality PC screen with clear high definition resolution enables a transparent, one-tool device to work, meet, and collaborate
  • The 8-inch Cisco TelePresence touch screen interface allows for simple control
  • Collaboration is natural with high definition content sharing, transparent one-touch sharing of high-definition (HD) content, and a built-in document camera feature
  • A Cisco TelePresence PrecisionHD camera enables video clarity and optimal F1.7, 45-65° or 50° field of view.
  • The EX60 is wall-mountable with select VESA brackets
  • EX60 supports resolutions up to 720p in both main stream and dual stream simultaneously

Display:

  • 21.5-in. LCD monitor (with LED backlight)
  • Resolution: 1920 x 1080 (16:9)
  • Contrast ratio: 1000:1
  • Viewing angle: 170°
  • Response time: 5 ms
  • Brightness: 225cd/m2

Security features:

  • Management via Secure HTTP (HTTPS) and Secure Shell (SSH) Protocol
  • IP administration password
  • Menu administration password
  • Disable IP services
  • Network settings protection
Item Numbers
UNSPSC: 45111902
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Cisco CTS-EX60-K9= Accessory is also known as CSC-CTSEX60K9=
