Cisco CTS-EX90= Accessory

Part Number: CTS-EX90=
Model: Parts

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
ITU-T Recommendation
H.320
Video Bridging
Point-to-Point
Image Sensor Size
1/3
Image Sensor Type
CMOS

Product Description:

  EX90 - Non encrypted versions spare

Cisco Parts Accessory Model Overview

Products and parts from Cisco.
Cisco CTS-EX90= Accessory Overview

The Cisco TelePresence System EX Series transforms the workplace by combining work, communications, and collaboration - all on the desktop with just the touch of a finger. Colleagues can instantly work together whether they are separated by a hallway, a street, or several time zones. As part of the EX Series, the Cisco TelePresence System EX90 (EX90) and Cisco TelePresence System EX60 (EX60) support vivid, lifelike 1080p30 video, natural collaboration, and the simplicity of a touch screen interface for a complete solution that helps ensure conversations are more productive.

Technical Information
ITU-T Recommendation:
H.320
Video Bridging:
Point-to-Point
Camera
Image Sensor Size:
1/3
Image Sensor Type:
CMOS
Video
Graphics Modes:
WUXGA
Maximum Video Resolution:
1920 x 1200
Maximum Frame Rate:
60 fps
Video Encoding:
  • H.239
  • H.261
  • H.263
  • H.263+
  • H.264
Audio
Microphone Form Factor:
Internal
Audio Encoding:
  • G.711
  • G.722
  • G.722.1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Interfaces/Ports
HDMI In:
Yes
HDMI Out:
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
Network (RJ-45):
Yes
USB:
Yes
Number of Network (RJ-45) Ports:
2
Number of HDMI Inputs:
1
Number of HDMI Outputs:
1
Number of Audio Line In:
1
Number of Audio Line Out:
2
Physical Characteristics
Height:
21.4"
Width:
22.3"
Depth:
6.8"
Weight (Approximate):
24.20 lb
Miscellaneous
Package Contents:
  • TelePresence EX 90 Web Conference Equipment
  • Codec
  • Display
  • Camera
  • Microphone and loudspeakers
  • Cables including: DVI-I-to-VGA cable, DVI-D cable, 3.5-mm jack audio cable, LAN cable, power adapter, and power cable
Additional Information:
  • Non encrypted version
  • A high-quality PC screen with clear high definition resolution enables a transparent, one-tool device to work, meet, and collaborate
  • The 8-inch Cisco TelePresence touch screen interface allows for simple control
  • Collaboration is natural with high definition content sharing, transparent one-touch sharing of high-definition (HD) content, and a built-in document camera feature
  • A Cisco TelePresence PrecisionHD camera enables video clarity and optimal F1.7, 45-65° or 50° field of view.

Display:

  • 24-in. LCD monitor
  • Resolution: 1920 x 1200 (16:9)
  • Contrast ratio: 1000:1
  • Viewing angle: 160°
  • Response time: 5 ms
  • Brightness: 300cd/m2

Audio features:

  • CD-quality 20-kHz stereo
  • Acoustic echo canceling
  • Automatic gain control
  • Automatic noise reduction
  • Active lip synchronization

Security features:

  • Management via Secure HTTP (HTTPS) and Secure Shell (SSH) Protocol
  • IP administration password
  • Menu administration password
  • Disable IP services
  • Network settings protection
Item Numbers
GTIN: 0882658419195
UPC: 882658419195
EAN: 0882658419195
UNSPSC: 45111902
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Cisco CTS-EX90= Accessory is also known as CSC-CTSEX90=
