Honeywell – Barcode Label Printer – Direct Thermal

Part Number: PC43KA003040003
Model: Parts

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Printing Technology
Direct Thermal

Product Description:

  PC43KIOSK, ICON300, WL 2/32 CN, CN PC

Honeywell Parts Accessory Model Overview

Products and parts from Honeywell.
Honeywell PC43KA003040003 Barcode Label Printer Overview

The PC43K all-in-one kiosk solution includes a tablet, printer, scanner, and software from a single vendor, making it extremely easy to use and develop custom applications to fit any business model.

The PC43K comes with an integrated scan engine, ScanPal™ EDA71 tablet on an articulating arm, PC43 direct thermal printer, I/O board, and wall/desk mount to ensure that it is ready for direct consumer operations.

The ScanPal EDA71 tablet is loaded with the world's most advanced and widely adopted mobile operating system, Android™ 8. The Android operating system is the most flexible platform for any ISV or mobile application developer to customize and develop applications that fit any business model. This enables our customers to easily configure and develop custom applications to take full advantage of the PC43K solution.

Security is a key element of the PC43K solution. Capable of full mobile device management (MDM) support, and with security patch releases for Android and centralized support from Honeywell, the PC43K is a complete, all-in-one kiosk solution.

With native support for comprehensive printer command languages, the PC43 direct thermal printer is simple to use and maintain. It comes with all necessary configuration applications such as a printer firmware updates app, which enables you to update the printer to the latest firmware to ensure that the printer is secure and performing to its optimal level.

Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
6 in/s
Maximum Print Resolution (dpi):
300
Maximum Print Length:
35.43"
Maximum Print Width:
4.20"
Barcode Symbology Supported:
  • AZTEC
  • Plessey
  • Code 49
  • Data Matrix
  • RSS-14
  • Maxi Code
  • PDF417
  • EAN-8
  • EAN-13
  • QR Code
  • PLANET
  • EAN.UCC 128
  • POSTNET
  • HIBC Code 128
  • HIBC Code 39
  • MSI (Modified Plessey)
  • Grid Matrix
  • Code 16K
  • Dot Code
Application/Usage:
  • Business
  • Desktop
Connectivity Technology:
Wireless
Memory
Standard Memory:
128 MB
Flash Memory:
128 MB
Interfaces/Ports
USB:
Yes
Network & Communication
Ethernet:
Yes
Bluetooth:
Yes
Wireless LAN Standard:
IEEE 802.11a/b/g/n/ac
Display & Graphics
Display Screen:
Yes
Screen Size:
7"
Display Screen Type:
LCD
Media Types & Handling
Media Type:
Label
Maximum Roll Diameter:
5"
Maximum Label Width:
4.65"
Maximum Label Length:
35.40"
Fonts & Emulation
Language Emulation:
  • EPL
  • ZPL II
  • DPL
  • IPL
Power Description
Power Source:
AC Supply
Frequency:
  • 50 Hz
  • 60 Hz
Environmental Conditions
Operating Temperature:
14°F (-10°C) - 104°F (40°C)
Storage Temperature:
4°F (-15.6°C) - 140°F (60°C)
Storage Relative Humidity:
10% - 80%
Physical Characteristics
Height:
9.8"
Width:
9.6"
Depth:
16.1"
Weight (Approximate):
10 lb
Miscellaneous
Platform Supported:
PC
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 45101512
Questions? Get help from a
Printer Expert!

How many labels will you print per day?

The Honeywell PC43KA003040003 Barcode Label Printer is also known as HSM-PC43KA003040003
