Metrologic MS3780 Fusion – Barcode Scanner – Corded – 1D

Part Number: MK3780-61B47
Model: MS3780 Fusion

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity
Corded
Form Factor
Handheld, Presentation
Interface Options
PS/2 Keyboard Wedge
Scanner Capability
1D

Product Description:

  PS/2 kit. Omni-Directional Laser. Includes PS/2 cable, power supply, and stand. Color: Dark Gray. Non-Cancelable/Non-Returnable.

Metrologic Fusion 3780 Barcode Scanner Model Overview

The Metrologic Fusion 3780 Handheld/Hands-Free Scanner has a primary 20-line omnidirectional scan pattern that allows for aggressive scanning of barcodes in any orientation or with a push of a button can switch to a targeted single line for menu scanning. This feature of the Fusion 3780 provides the ability to pass over other barcodes, selecting only the required code. No other scanner offer quite as much control as the Fusion 3780. Hands free operation in the stand for presentation scanning reduces operator fatigue and multiple sleep modes reduce power consumption. The Fusion 3780's optional EAS integration allows users to deactivate and EAS tag and decode a barcode in a single scan.
Metrologic MK3780-61B47 Barcode Scanner Overview

Fusion MS3780 Bar Code Reader is an affordable hand-held omni directional laser scanner with single-line capability that increases retail checkout system efficiency with its automatic in-stand operation, optionally integrated EAS, and industry-leading scan performance.

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:

Autodiscriminates all standard 1D bar codes, including RSS-Expanded,RSS-14 and RSS-14 Limited.

Light Source:
Laser
Maximum Scan Resolution:
5 mil
Scan Pattern:
  • Omni-directional
  • Single Line
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
5 V DC
Power Supply Included:
Yes
Physical Characteristics
Color:
Dark Gray
Height:
2.9"
Width:
2.6"
Depth:
7.4"
Weight (Approximate):
6.90 oz
Miscellaneous
Package Contents:
  • Fusion MS3780 Bar Code Reader
  • 110 VAC Power Supply
Additional Information:

Supported Interfaces:

  • Serial
  • Keyboard Wedge
  • IBM 468X/469X
  • USB
  • OCIA
  • Certifications & Standards:
    • WEEE

    Laser Class:

    • Class 1; IEC60825-1:1993/A1:1997+A2:2001
    • Class 1; EN60825-1:1994/A11:1996+A2:2001

    EMC:

    • FCC
    • ICES-003
    • EN55022 Class A
    Environmental Certification:
    WEEE
    Warranty
    Limited Warranty:
    3 Year
    Item Numbers
    UNSPSC: 43211701
