Ubiquiti Networks U6-LR-US Wireless Access Points

Part Number: U6-LR-US
Model: UniFi 6 Long-Range
Add to My Shopping List Add to Compare
$210.89

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
802.11ax
Bluetooth Standard
Bluetooth 5
Frequency Band
2.40 GHz5 GHz
Wireless Transmission Speed
2.93 Gbit/s

Product Description:

  UniFi 6 Long-Range Access Point.
Explore all Ubiquiti Networks UniFi 6 Long-Range Wireless Access Points
Add to Quote
Ubiquiti Networks U6-LR-US Wireless Access Points
Ubiquiti Networks U6-LR-US Wireless Access Points
Ubiquiti Networks U6-LR-US Wireless Access Points
Ubiquiti Networks U6-LR-US Wireless Access Points
Ubiquiti Networks U6-LR-US Wireless Access Points
Ubiquiti Networks U6-LR-US Wireless Access Points Ubiquiti Networks U6-LR-US Wireless Access Points Ubiquiti Networks U6-LR-US Wireless Access Points Ubiquiti Networks U6-LR-US Wireless Access Points Ubiquiti Networks U6-LR-US Wireless Access Points
Full specifications (PDF)

Ubiquiti Networks UniFi 6 Long-Range Wireless Access Points Model Overview

The UniFi 6 Long-Range Access Point (U6-LR) is your solution for high-performance wireless networking in both indoor and semi-outdoor environments. Leveraging cutting-edge WiFi 6 technology, it delivers exceptional coverage with an aggregate radio rate of up to 3.0 Gbps. Ideal for enterprise settings, the U6-LR is not only robust but also easy to integrate into any environment, thanks to its IP54 weatherproof rating and versatile mounting options. With advanced features like Bluetooth Low Energy for location-based services, this access point is a smart investment for future-proofing your connectivity needs.


Key Features
  • WiFi 6 Technology: Achieve faster speeds and greater capacity.
  • Aggregate Radio Rate: Up to 3.0 Gbps for seamless performance.
  • IP54 Weatherproofing: Suitable for both indoor and semi-outdoor installations.
  • Bluetooth Low Energy: Enhance location-based services.
  • High Client Capacity: Supports over 300 concurrent clients.

Specifications
  • Dimensions: 220 x 48 mm (8.66 x 1.89 inches)
  • Weight: Without Mount: 800 g (1.76 lb), With Mount: 930 g (2.05 lb)
  • Mounting: Wall/Ceiling (Kits Included)
  • Operating Temperature: -30 to 60°C (-22 to 140°F)
  • Processor: Dual-Core Cortex A53 at 1.35 GHz
  • Memory: 512 MB
  • Power Supply: PoE+, Passive PoE (48V)
  • Supported Voltage Range: 44 to 57VDC
  • Max. Power Consumption: 16.5W
  • Concurrent Clients: 300+
  • Certifications: CE, FCC, IC
Ubiquiti Networks U6-LR-US Wireless Access Points Overview

Best-in-class Wi-Fi coverage and performance

With its Wi-Fi 6 capability, the U6-LR will strengthen your enterprise environment with the widest, most reliable coverage yet.

Wi-Fi 6

Better performance in crowded environments

4-Stream AP

Faster download and upload speeds

Full-duplex 1 Gbps

Support full-duplex 1 Gbps TCP/IP performance

Bluetooth 5.0

Fast discovery and setup

Four-stream high-efficiency Wi-Fi 6 technology

Wi-Fi 6 APs deliver an aggregate radio rate of up to 3 Gbps with 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz 4x4 MIMO radios

Powerful, wider wireless coverage

The U6-LR access point utilizes Wi-Fi 6 technology to provide strong and expansive wireless coverage to all enterprise networking environments.

Simultaneously connect to more devices

Create and support over 300 distinct client connections.

Easily set up and grow your network

The U6-LR access point seamlessly integrates with the UniFi Network Controller and simplifies network bridging.

Full specifications (PDF)
Technical Information
Wireless LAN Standard:
802.11ax
Bluetooth Standard:
Bluetooth 5
Frequency Band:
  • 2.40 GHz
  • 5 GHz
Wireless Transmission Speed:
2.93 Gbit/s
MIMO Technology:
Yes
Data Encryption:
Yes
Encryption Standard:
  • WPA
  • WPA2
  • WPA3
  • WPA-PSK
  • WPA-ENT
Interfaces/Ports
Ethernet Technology:
Gigabit Ethernet
Number of Network (RJ-45) Ports:
1
PoE PD Port:
Yes
Power Description
Power Consumption:
16.50 W
Physical Characteristics
Form Factor:
  • Wall Mountable
  • Ceiling Mountable
Depth:
1.9"
Diameter:
8.7"
Weight (Approximate):
1.76 lb
Miscellaneous
Package Contents:
  • UniFi 6 Long-Range Access Point
  • Wall/Ceiling Kit
Environmentally Friendly:
Yes
Environmental Compliance:
Waste Electrical and Electronic Equipment Directive (WEEE)
Item Numbers
UNSPSC: 43222631
