Datalogic PD9630 – Barcode Scanner

Part Number: PD9630-SRK1
Model: PD9630
3-year Premium Plus ($109.15)
3-year Premium ($54.45)
No Support
Add to My Shopping List Add to Compare
$416.88
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Scanning Capability
1D2D
Barcode Symbology Supported
1D: Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes. 2D: Aztec Code China Han Xin Code Data Matrix MaxiCode Micro QR Code QR Codee Dot code Postal Codes: Australian Post China Post IMB Japanese Post KIX Post Planet Code Portuguese Post Postnet Royal Mail Code (RM4SCC) Swedish Post Digital Watermarking: Digimarc Barcodes (PD9630-HP and PD9630-DC)
Light Source
LED

Product Description:

  Mobile Computer, Datalogic PowerScan PD9630-SR, Standard Range, USB Kit. Includes: Scanner, USB Cable (Part# CAB-553)
Explore all Datalogic PD9630 Barcode Scanners
Add to Quote
Datalogic PD9630-SRK1 Barcode Scanner
Datalogic PD9630-SRK1 Barcode Scanner
Datalogic PD9630-SRK1 Barcode Scanner
Datalogic PD9630-SRK1 Barcode Scanner
Datalogic PD9630-SRK1 Barcode Scanner
Datalogic PD9630-SRK1 Barcode Scanner
Datalogic PD9630-SRK1 Barcode Scanner
Datalogic PD9630-SRK1 Barcode Scanner
Datalogic PD9630-SRK1 Barcode Scanner Datalogic PD9630-SRK1 Barcode Scanner Datalogic PD9630-SRK1 Barcode Scanner Datalogic PD9630-SRK1 Barcode Scanner Datalogic PD9630-SRK1 Barcode Scanner Datalogic PD9630-SRK1 Barcode Scanner Datalogic PD9630-SRK1 Barcode Scanner Datalogic PD9630-SRK1 Barcode Scanner
Frequently Purchased Together
Total: $00.00
Full specifications (PDF)

Datalogic PD9630 Barcode Scanner Model Overview

The PowerScan PD9630 is an advanced barcode scanner designed for high-performance and demanding environments. It offers document capture, color sensor technology, and wireless communication capabilities, making it the perfect choice for industries requiring fast, reliable scanning. Built with rugged durability, the PD9630 offers excellent readability in all lighting conditions and can handle drops, dust, and moisture.


Key Features:

Document Capture: Scans both barcodes and documents, streamlining workflows.

Color Sensor Technology: Improves reading performance, even in low-contrast environments.

Rugged Build: IP65 and IP67 ratings for durability in harsh environments.

Wireless Connectivity: Bluetooth for flexible use in various settings.

Omnidirectional Reading: Ensures fast and accurate scanning of 1D, 2D, and postal codes.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:
1D:
  • Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes.
2D:
  • Aztec Code
  • China Han Xin Code
  • Data Matrix
  • MaxiCode
  • Micro QR Code
  • QR Codee
  • Dot code
Postal Codes:
  • Australian Post
  • China Post
  • IMB
  • Japanese Post
  • KIX Post
  • Planet Code
  • Portuguese Post
  • Postnet
  • Royal Mail Code (RM4SCC)
  • Swedish Post
Digital Watermarking:
  • Digimarc Barcodes (PD9630-HP and PD9630-DC)
Light Source:
LED
Image Sensor Type:
Imager
Scan Pattern:
Omni-directional
Scanner Range:
Standard Range
Field of View (Horizontal):
38°
Field of View (Vertical):
24°
Reading Angle (Skew):
52°
Reading Angle (Pitch):
52°
Reading Angle (Roll):
360°
Maximum Ambient Light:
100000 lux
Drop Specification:
Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F
Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °F

Minimum Print Contrast:
15%
Maximum Element Resolution (DataMatrix):
10 mil
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Form Factor:
Handheld
Rugged:
Yes
Product Color:
  • Yellow
  • Black
Height:
7.5"
Width:
3.1"
Length:
5.5"
Weight (Approximate):
11.22 oz
Miscellaneous
Ingress Protection (IP) Rating:
  • IP67
  • IP65
Application/Usage:
  • Manufacturing
  • Asset Tracking
  • Warehouse
  • Logistics
  • Picking
  • Sorting
  • Inventory
  • Industrial
Item Numbers
UNSPSC: 43211701
